A single system processes round tubes, square and rectangular tubes, as well as open profiles such as channels, angles, and I-beams, expanding application flexibility and maximizing return on investment.
24ft
Max. Processable Tube Length
1100lb
Max. Tube Weight
10ft
Max. Finished Part Length
100RPM
Max. Chuck Rotational Speed
4000IPM
Max. Rapid Traverse Speed
The cutting area features a fully enclosed design, enhancing operational safety and improving the overall workshop environment.
Camera-based weld seam recognition automatically identifies weld seam locations, ensuring cutting accuracy and consistent finished part appearance.
Optional bevel cutting enables multi-angle bevel processing, reducing secondary welding and post-processing operations while improving overall efficiency.
An integrated infrared measuring system performs non-contact tube detection and automatically identifies the tube center, minimizing manual alignment errors and ensuring stable, accurate cutting.
